Sheet

Requires configuration of the Customer Privacy capability to be rendered.

The Sheet component displays essential information for customers at the bottom of the screen, appearing above other elements. Use it sparingly to avoid distracting customers during checkout. This component requires access to Customer Privacy API to be rendered.

The library automatically applies the WAI-ARIA Dialog pattern to both the activator and the sheet content.

Anchor to propertiesProperties

Anchor to accessibilityLabel
accessibilityLabel
string

A label that describes the purpose of the modal. When set, it will be announced to users using assistive technologies and will provide them with more context.

This overrides the heading prop for screen readers.

Anchor to defaultOpen
defaultOpen
boolean
Default: false

Indicates whether the Sheet should be open by default. This property is necessary in some cases, but its usage is generally discouraged due to potential negative impacts on user experience.

Developers should:

  • Only set this property to true when there are vitally important behaviors of the application that depend on the user interacting with the sheet.
  • Make every effort to conditionally hide the sheet based on the state of checkout. An explicit example is custom privacy consent, where the sheet should only be displayed when consent is necessary and has not yet been explicitly given by the user.

This property is useful for when the Sheet needs to be rendered on the page load and not triggered by a user action. The property should only take effect when the Sheet is rendered for the first time. To toggle the Sheet after it has been rendered, use the ui.showOverlay() method instead.

Anchor to heading
heading
string

A title that describes the content of the sheet.

Anchor to id
id
string

A unique identifier for the element.

Was this section helpful?

Anchor to eventsEvents

Anchor to afterhide
afterhide
((event: <typeof tagName>) => void) | null

Callback fired when the overlay is hidden after any animations to hide the overlay have finished.

Anchor to aftershow
aftershow
((event: <typeof tagName>) => void) | null

Callback fired when the overlay is shown after any animations to show the overlay have finished.

Anchor to hide
hide
((event: <typeof tagName>) => void) | null

Callback fired after the overlay is hidden.

Anchor to show
show
((event: <typeof tagName>) => void) | null

Callback fired after the overlay is shown.

Was this section helpful?

Anchor to slotsSlots

Anchor to primary-action
primary-action
HTMLElement

The primary action to perform, provided as a button type element.

Anchor to secondary-actions
secondary-actions
HTMLElement

The secondary actions to perform, provided as a button type element.

Was this section helpful?

Anchor to methodsMethods

Anchor to hideOverlay
hideOverlay
() => void
required

Method to hide an overlay.

Was this section helpful?

Code

<!-- This component requires access to Customer Privacy API to be rendered. -->
<s-button commandFor="consent-sheet">Open Sheet</s-button>
<s-sheet id="consent-sheet" heading="Sheet" accessibilityLabel="A sheet with text content">
<s-text>Sheet Content</s-text>
</s-sheet>

Preview

Anchor to shopify-controlled-surfacesShopify-controlled surfaces

To prevent disruptions during checkout, we maintain strict design control over key areas of the Sheet component. These Shopify-controlled elements include:

Locations of elements

The Sheet elements (header, content, action buttons, and dismiss button) are strategically positioned and sized to present vital information upfront.

Locations of header and content Locations of dismiss button and actions

Padding and spacing

Padding and spacing

Maximum height

To balance customer attention and task completion, a maximum height is set for the Sheet component.

Small screen maximum height Large screen maximum height

When content pushes the sheet to exceed this limit, the following UI behaviors are triggered:


Heading and content are scrollable

Heading and content are scrollable

Expand pill appears to allow customers to view the entire content

Expand pill to allow maximum height

Actions slot and dismiss button remain fixed

Actions slot and dismiss button remain fixed
Was this section helpful?

Anchor to privacy-consent-requirementsPrivacy consent requirements

Content

For the best customer experience, ensure content is brief and to the point.

Shows content that is brief and to the point

Various strategies can be employed to avoid content scrolling.


Use short content

Use short content

Use small text size

Use small text size

Remove the header

Remove the header

Actions slot

The actions slots allows customers to make decisions and is split into primary and secondary sections.

Actions slot

Primary section

Contains primary actions for customer decisions on the sheet's prompt. Up to two buttons are allowed. Keep the button's content brief so that it doesn't wrap to more than one line.

Primary section

Secondary section

Contains action that is unrelated to the sheet's prompt. Only one button is allowed. A modal can be activated when engaging with the secondary action. Keep the button's content brief so that it doesn't wrap to more than one line.

Secondary section

Consent, denial of consent, and sheet dismissal

Consent

When a customer expresses consent by pressing the acceptance button, cookies will load and the sheet should not re-appear on refresh.


Denial of consent

When a customer expresses denial of consent by pressing the rejection button, cookies will not load and the sheet will not re-appear on refresh.


Sheet dismissal

When a customer neither grants nor denies consent by pressing the dismiss button, cookies will not load and the sheet will re-appear on refresh.

Sheet dismissal
